added Matlab demo around mex-interfaces

demoFelzenszwalbSegmentation.m

@@ -0,0 +1,69 @@
+% demoFelzenszwalbSegmentation
+%
+% author: Alexander Freytag
+% date:   28-03-2014 (dd-mm-yyyy)
+%
+% brief:  small demo showing how to use the felzenszwalb segmentation code
+%         via Matlab and how to adjust parameter specifications.
+
+
+%% ( 1 ) GET INPUT
+
+%read image ...
+img = imread( 'data/test.png');
+
+
+% show input image in figure
+figOrig = figure;
+set ( figOrig, 'name', 'Input image');
+imshow ( img );
+
+
+%% ( 2 ) PERFORM SEGMENTATION WITH DEFAULT SETTINGS
+
+
+% call felzenszwalb segmentation using our mex-interface
+segResult = segmentFelzenszwalb( img );
+
+% show segmentation result in separate figure
+figSegResult = figure;
+set ( figSegResult, 'name', 'Segmentation result');
+
+imshow ( segResult );
+% make region colors visually distinguishable
+colormap ( 'lines' );
+
+%% ( 3 ) PERFORM SEGMENTATION WITH SPECIFIED SETTINGS
+
+d_sigma              = 0.75;   % default: 0.5
+i_k                  = 700;   % default: 500
+i_minSize            = 50;    % default: 50
+b_computeColorOutput = true;  % default: false
+s_destination        = '';    % default: ''
+b_verbose            = false; % default: false
+
+srManSpec = segmentFelzenszwalb( img, d_sigma, i_k, i_minSize, ...
+                                 b_computeColorOutput, ...
+                                 s_destination, ...
+                                 b_verbose...
+                               );
+
+% show segmentation result in separate figure
+figSRManSpec = figure;
+set ( figSRManSpec, 'name', 'Segmentation result, man. specified');
+
+imshow ( srManSpec );
+
+% actually, another linespec is not needed, since the output is already a
+% nice RGB image. However, for easier visual comparison, we again apply the
+% matlab color mapping here.
+colormap ( 'lines' );
+
+
+% wait for user input
+pause
+
+% close images
+close ( figOrig );
+close ( figSegResult );
+close ( figSRManSpec );
